A table-typed motorized vehicle
SB-7500
-
product video -
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
A motorized table-type with the divided 4 sections
of the extended working table
The length of the extended working table
3,005mm
The height of a basic working table
865mm
The length of a basic working table
1,390mm
The height of a basic working table
2,715mm
The maximum height available for works 4.5m
865mm
The height of a basic working table
The maximum height available for works
4,515mm
A function of adjusting the level for the front, left and right on the sloped topography
Major functions of product
A smart control system
Touch screen/auto leveling
Voice alert/self-diagnosis
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
Double cylinder support
Prevents platform shaking and
frame deformation
AC motor installed
Prevents rollback when stopped on slopes
Semi-permanent lifespan
Dedicated joystick
Fine adjustment and
Simple and convenient operation
An automatic extension of working table
Auxiliary extension during slide
Automatic platform extension
A remote control system
It is possible for simple and convenient operation
Easy operation available
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
Low power alarm system
With advance alarm system
Prevents battery discharge
Fall prevention safety device
With double safety lock
User protection
An audio system
A radio and a cigar jack
Equipped with multi-purpose storage
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
Low center of gravity design
When using left/right leveling
Excellent stability
Uses premium dedicated battery
High-performance Longest
6 units of 8V installed
Communication system
Controller communication check
Easy quick A/S service
Major Specification
| Item | Description |
|---|---|
| Name of Machine | Aerial Lift Truck |
| Type | SB-7500 |
| Dimension(Length X Width X Height) | 2,890 × 1,460 × 2,005 |
| Upon extension of the extended table (mm) | 3,005 |
| Max. ascending height (mm) | 2,715 |
| The height up to the working table upon max. descending (mm) | 865 |
| A horizontal angle of the left, right and the front (˚) | 10 / 10 / 10 |
| Item | Description |
|---|---|
| Weight of Vehicle (kg) | 1,502 |
| Max. Load (kg) | 250 |
| Running Method | Infinite Track Type (driven by a motor) |
| A driving motor type | 48V, 2.0KW x 2EA |
| An illumination type | A lever type (a joystick) |
| Running Speed (km/h) | 2.4 |
| Type of Hydraulic Device | Hydraulic Power Pack(The highest oil pressure15MPa) |
A video of product
A table-typed motorized vehicle
SB-7500S
-
product video
-
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
A motorized table-type with the divided 4 sections
of the extended working table
The length of the extended working table
2,435mm
The height of a basic working table
865mm
The length of a basic working table
1,328mm
The height of a basic working table
2,140mm
The maximum height available for works 3.9m
865mm
The height of a basic working table
The maximum height available for works 3,940mm
A function of adjusting the level for the front, left and right on the sloped topography
Major functions of product
A smart control system
Touch screen/auto leveling
Voice alert/self-diagnosis
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
Double cylinder support
Prevents platform shaking and
frame deformation
High-performance motor equipped
Prevents rollback when stopped on slopes
Semi-permanent lifespan
Dedicated joystick
Fine adjustment and
Simple and convenient operation
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
A remote control system
It is possible for simple and convenient operation
Easy operation available
Communication system
Controller communication check
Easy quick A/S service
Low power alarm system
With advance alarm system
Prevents battery discharge
Fall prevention safety device
With double safety lock
User protection
An audio system
A radio and a cigar jack
Equipped with multi-purpose storage
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
An automatic extension of working table
Auxiliary extension during slide
Automatic platform extension
Uses premium dedicated battery
High-performance Longest
6 units of 8V installed
Optimal safety
Distributes load across entire track
Excellent stability
Major Specification
| Item | Description |
|---|---|
| Name of Machine | Aerial Lift Truck |
| Type | SB-7500S |
| Dimension(Length X Width X Height) | 2,265 × 1,328 × 1,915 |
| Upon extension of the extended table (mm) | 2,435 |
| Max. ascending height (mm) | 2,140 |
| The height up to the working table upon max. descending (mm) | 865 |
| A horizontal angle of the left, right and the front (˚) | 8 / 8 / 8 |
| Item | Description |
|---|---|
| Weight of Vehicle (kg) | 1,075 |
| Max. Load (kg) | 200 |
| Running Method | Infinite Track Type (driven by a motor) |
| A driving motor type | 48V, 1.3KW x 2EA |
| An illumination type | A lever type (a joystick) |
| Running Speed (km/h) | 2.4 |
| Type of Hydraulic Device | Hydraulic Power Pack(The highest oil pressure15MPa) |
A table-typed motorized vehicle
SB-7600S
-
product video
-
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
A motorized table-type with the divided 4 sections
of the extended working table
The length of the extended working table
2,050mm
The height of a basic working table
722mm
The length of a basic working table
1,300mm
The height of a basic working table
1,800mm
The maximum height available for works 3.6m
722mm
The height of a basic working table
The maximum height available for works 3,600mm
A function of adjusting the level for the left and right on the sloped topography
Major functions of product
Low power alarm system
With advance alarm system
Prevents battery discharge
Fall prevention safety device
With double safety lock
User protection
High-performance motor equipped
Prevents rollback when stopped on slopes
Semi-permanent lifespan
Dedicated joystick
Fine adjustment and
Simple and convenient operation
Uses premium dedicated battery
High-performance Longest
6 units of 8V installed
Optimal safety
Distributes load across entire track
Excellent stability
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
Double cylinder support
Prevents platform shaking and
frame deformation
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
Low center of gravity design
When using left/right leveling
Excellent stability
A remote control system
It is possible for simple and convenient operation
Easy operation available
Communication system
Controller communication check
Easy quick A/S service
Major Specification
| Item | Description |
|---|---|
| Name of Machine | A table-typed motorized vehicle |
| Type | SB-7600S |
| Dimension(Length X Width X Height) | 2,050 × 1,330 × 1,750 |
| Item | Description |
|---|---|
| A driving motor type | 48V, 1.3KW × 2EA |
| Weight and Speed | 950kg, 2.2km/h |
| Max. Load | 200kg |
A table-typed motorized vehicle
SB-7700
-
product video
-
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
A motorized table-type with the divided 4 sections
of the extended working table
The length of the extended working table
5,125mm
The height of a basic working table
770mm
The height of a basic working table
1,485mm
The height of a basic working table
2,300mm
The maximum height available for works 4.1m
770mm
The height of a basic working table
The maximum height available for works 4,100mm
A function of adjusting the level for the left and right on the sloped topography
Major functions of product
A smart control system
Touch screen/auto leveling
Voice alert/self-diagnosis
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
Double cylinder support
Prevents platform shaking and
frame deformation
AC motor installed
Prevents rollback when stopped on slopes
Semi-permanent lifespan
Dedicated joystick
Fine adjustment and
Simple and convenient operation
An automatic extension of working table
Auxiliary extension during slide
Automatic platform extension
A remote control system
It is possible for simple and convenient operation
Easy operation available
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
Low power alarm system
With advance alarm system
Prevents battery discharge
Fall prevention safety device
With double safety lock
User protection
An audio system
A radio and a cigar jack
Equipped with multi-purpose storage
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
Low center of gravity design
When using left/right leveling
Excellent stability
Uses premium dedicated battery
High-performance Longest
6 units of 8V installed
Communication system
Controller communication check
Easy quick A/S service
Major Specification
| Item | Description |
|---|---|
| Name of Machine | A table-typed motorized vehicle |
| Type | SB-7700 |
| Dimension(Length X Width X Height) | 2,750 × 1,860 × 1,570 |
| Item | Description |
|---|---|
| A driving motor type | 48V, 2.0KW × 2EA |
| Weight and Speed | 1,688kg, 2.5km/h |
| Max. Load | 250kg |
A table-typed motorized vehicle
SB-7800
-
product video
-
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
A motorized table-type with the divided 4 sections
of the extended working table
The length of the extended working table
3,190mm
The height of a basic working table
755mm
The length of a basic working table
1,200mm
The height of a basic working table
2,000mm
The maximum height available for works 3.8m
755mm
The height of a basic working table
The maximum height available for works 3,800mm
A function of adjusting the level for the left and right on the sloped topography
Major functions of product
A smart control system
Touch screen/auto leveling
Voice alert/self-diagnosis
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
Double cylinder support
Prevents platform shaking and
frame deformation
High-performance motor equipped
Prevents rollback when stopped on slopes
Semi-permanent lifespan
Dedicated joystick
Fine adjustment and
Simple and convenient operation
An automatic extension of working table
Auxiliary extension during slide
Automatic platform extension
A remote control system
It is possible for simple and convenient operation
Easy operation available
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
Low power alarm system
With advance alarm system
Prevents battery discharge
Fall prevention safety device
With double safety lock
User protection
An audio system
A radio and a cigar jack
Equipped with multi-purpose storage
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
Low center of gravity design
When using left/right leveling
Excellent stability
Uses premium dedicated battery
High-performance Longest
6 units of 8V installed
Communication system
Controller communication check
Easy quick A/S service
Major Specification
| Item | Description |
|---|---|
| Name of Machine | A table-typed motorized vehicle |
| Type | SB-7800 |
| Dimension(Length X Width X Height) | 2,270 × 1,340 × 1,835 |
| Item | Description |
|---|---|
| A driving motor type | 48V, 1.3KW × 2EA |
| Weight and Speed | 1,184kg, 2.2km/h |
| Max. Load | 200kg |
A boom-typed motorized vehicle
SB-8000N
-
product video
-
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
The best workability with
infinite rotation of SB8000N_360 degree
The height of a basic working table
3,680mm
The maximum height available for works 5.4m
437mm
1,705mm
The maximum height available for works
5,480mm
A horizontal access work (Width of works 3m)
A horizontal access work
Minimizing damages on fruit trees
Width available for works
3,000mm
A horizontal control device
Left
Right
Front
Rear
Increasing the degree of freedom of works
Reducing vibration of the boarding platform, improving work efficiency
2-step boom
1-step boom
Major functions of product
Horizontal control system
Automatic/manual operation
Available horizontal control
Low power alarm system
With advance alarm system
Prevents battery discharge
Uses premium dedicated battery
High-performance Longest
6 units of 8V installed
An audio system
A radio and a cigar jack
Equipped with multi-purpose storage
AC motor installed
Prevents rollback when stopped on slopes
Semi-permanent lifespan
Dedicated joystick
Fine adjustment and
Simple and convenient operation
A smart control system
Touch screen/auto leveling
Voice alert/self-diagnosis
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
Applying the first 2-joint in the country
Reduces work time and
Minimizes damage to fruit trees
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
Communication system
Controller communication check
Easy quick A/S service
Major Specification
| Item | Description |
|---|---|
| Type | SB-8000N |
| Dimension(Length X Width X Height) | 2,660 × 1,350 × 1,705 |
| Max. ascending height (mm) | 3,680 |
| The height up to the working table upon max. descending (mm) | 437 |
| A horizontal angle of the left, right and the front, rear (˚) | 10 / 10 / 10 / 10 |
| Rotation angle (˚) | a 360-degree revolution |
| 1-step·2-step angle (˚) | 1-step 70 degrees, 2-step 95 degrees |
| Item | Description |
|---|---|
| Weight of Vehicle (kg) | 1,155 |
| Max. Load (kg) | 100 |
| Running Method | Infinite Track Type (driven by a motor) |
| A driving motor type | 48V, 2.0KW × 2EA |
| An illumination type | A lever type (a joystick) |
| Running Speed (km/h) | 2.4 |
| Type of Hydraulic Device | Hydraulic Power Pack(The highest oil pressure15MPa) |
A video of product
A boom-typed motorized vehicle
SB-6000S
-
product video
-
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
140° left and right rotation
Workable width 6m
The height of a basic working table
3,140mm
The maximum height available for works 5m
379mm
1,470mm
The maximum height available for works
4,930mm
A horizontal access work (Width of works 3m)
A horizontal access work
Minimizing damages on fruit trees
Width available for works
3,000mm
A horizontal control device
Left
Right
Increasing the degree of freedom of works
Reducing vibration of the boarding platform, improving work efficiency
2-step boom
1-step boom
Major functions of product
Low power alarm system
With advance alarm system
Prevents battery discharge
Uses premium dedicated battery
High-performance Longest
6 units of 8V installed
An audio system
A radio and a cigar jack
Equipped with multi-purpose storage
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
Dedicated joystick
Fine adjustment and
Simple and convenient operation
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
Applying the first 2-joint in the country
Reduces work time and
Minimizes damage to fruit trees
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
Low center of gravity design
When using left/right leveling
Excellent stability
Communication system
Controller communication check
Easy quick A/S service
Major Specification
| Item | Description |
|---|---|
| Name of Machine | Aerial Lift Truck |
| Type | SB-6000S |
| Dimension(Length X Width X Height) | 2,780 × 1,350 × 1,470 |
| Max. ascending height (mm) | 3,130 |
| The height up to the working table upon max. descending (mm) | 379 |
| A horizontal angle of the left, right (˚) | 10 / 10 |
| 1-step·2-step angle (˚) | 1-step 70 degrees, 2-step 110 degrees |
| Item | Description |
|---|---|
| Weight of Vehicle (kg) | 947 |
| Max. Load (kg) | 100 |
| Running Method | Infinite Track Type (driven by a motor) |
| A driving motor type | 48V, 2.0KW × 2EA |
| An illumination type | A lever type (a joystick) |
| Running Speed (km/h) | 2.4 |
| Type of Hydraulic Device | Hydraulic Power Pack(The highest oil pressure15MPa) |
A multipurpose-typed motorized vehicle
SB-9000
-
product video
-
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
A function of a vehicle for high-place works
Width available for works 2.22m
A length when a working table is attached
1,320mm
The length of the extended working table
2,220mm
The height of a basic working table
2,545mm
A length of the extended working table
520mm
The maximum height available for works 4.3m
The height of a basic working table
1,830mm
Available for works with front-tilted 6 degree and back-tilted 12 degree of a forklift
Major functions of product
Low power alarm system
With advance alarm system
Prevents battery discharge
Wireless remote charging
No cable connection needed
Convenient wireless charging
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
AC motor installed
Prevents rollback when stopped on slopes
Semi-permanent lifespan
Dedicated detachable remote control system
With dedicated control remote
Easy operation available
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
Detachable platform
With the detachable working table,
it is possible to extend the working table and to work at a high place.
Achieves excellent loading performance
When loading apple pallets
2-tier loading available
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
Communication system
Controller communication check
Easy quick A/S service
Major Specification
| Item | Description |
|---|---|
| Dimension(Length X Width X Height) | 2,590 × 1,202 × 1,830 |
| Upon extension of the extended table (mm) | 2,220 |
| Max. ascending height (mm) | 2,545 |
| A horizontal angle of the front, rear (˚) | 6 / 12 |
| Type of Hydraulic Device | Hydraulic Power Pack(The highest oil pressure15MPa) |
| Item | Description |
|---|---|
| Weight of Vehicle (kg) | 1,517 |
| Running Method | Infinite Track Type (driven by a motor) |
| A driving motor type | 48V, 2.0KW × 2EA |
| An illumination type | A lever type (a joystick) |
| Running Speed (km/h) | 2.4 |
A video of product
A multipurpose-typed motorized vehicle
SB-8500
-
product video
-
AR(augmented reality)
basic type -
AR(augmented reality)
expandable
MORE
Features and Performance
270° left/right rotation & mast/boom lifting and
A horizontal control device 6m
The height of a basic working table
5,500mm
The maximum height available for works 7.3m
Horizontal entry work (working width 2.3m)
A horizontal access work
Minimizing damages on fruit trees
Width available for works
2,300mm
A horizontal control device
Left
Right
Major functions of product
A smart control system
Touch screen/auto leveling
Voice alert/self-diagnosis
Distilled water refill alarm system
With advance alarm system
Maintains battery performance
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
Vibration minimizing structure
Low center design and counter balance applied
Horizontal and low center of gravity
Counter balance design
Fall prevention safety device
With double safety lock
User protection
Low power alarm system
With advance alarm system
Prevents battery discharge
AC motor installed
Prevents rollback when stopped on slopes
Semi-permanent lifespan
Dedicated joystick
Fine adjustment and
Simple and convenient operation
A remote control system
It is possible for simple and convenient operation
Easy operation available
A safety device for emergency stop
Stops operation in emergency
Ensures worker safety
Major Specification
| Item | Description |
|---|---|
| Name of Machine | Mast-type Motorized High-Place Work Vehicle |
| Type | SB-8500 |
| Dimension(Length X Width X Height) | 2,699 × 1,500 × 2,200 |
| Platform Height (mm) | Min 600, Max 5,500 (mm) |
| Item | Description |
|---|---|
| Weight and Speed (kg) | 1,530kg, Forward/Reverse 0 ~ 3.0km/h |
| Hydraulic Power | Power pack type (max 15MPa) |
| A driving motor type | 48V, 2.0KW × 2EA |
| Max. Load | 100kg |
