Motorized Vehicle for High-Place Works
Products of Seongbu Industry representing the domestic agricultural machinery market are safely and usefully used and we have made efforts to produce the best quality.
> Prooduct > Motorized Vehicle for High-Place Works

Motorized Vehicle for High-Place Works

  • A table-typed motorized vehicle
  • A boom-typed motorized vehicle
  • A multipurpose-typed motorized vehicle
A plate-typed and motorized high-place work vehicle
SB-7500
A motorized table-type with the divided 4 sections of the extended working table
Certified as a new technology by Ministry of Agriculture, Food and Rural Affairs
Possessing many patents regarding agricultural vehicles for high-place works
MORE
Features and Performance
A motorized table-type with the divided 4 sections
of the extended working table
It is possible to extend the working table so that a work can be done up to 4.5m of the span length.
With the divided 4 sections, it is possible to extend them respectively according to worker’s convenience.
The length of the extended working table 3,005mm
The height of a basic working table 860mm The length of a basic working table 1,390mm
The height of a basic working table 2,690mm
The maximum height available for works 4.5m
860mm The height of a basic working table
The maximum height available for works 4,490mm
A function of adjusting the level for the front, left and right on the sloped topography
Major functions of product
A smart control system
a touch screen, an emergency mode operation, voice-enabled
Easily operable even by women and the aged
A double-cylinder type
Preventing the working table from shaking by a double-cylinder support
Safe without deformation of a frame
An audio system
A radio and a cigar jack
With a multipurpose compartment, it is convenient upon working.
A low-centered design
With a low-centered design method,
excellent safety upon a function of the left and right level.
Amenities
A non-slip pad and a cushion withstanding the equipment
An EVA cap to prevent rust and foreign materials and a platform brush
A safety device for emergency stop
It guarantees the safety of a worker
since it stops operation upon emergency by the emergency stop button.
A communication system
It is easy to provide a quick customer service
by an alarm and a signal check through communication between controllers.
A LED light
A self-waterproofing function
A super power-saving LED light
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
minimizing vibration
AC motor installed
A semi-permanent life, preventing it from being pushed back upon stopping a back-piece
Upon illumination, it is possible for a fine control.
An automatic extension of working table
Upon sliding, it is easy for a worker to use
since the subsidiary extended working table is automatically opened.
A remote control system
It is possible for simple and convenient operation
by a separate remote controller.
Optimal safety
Loads distributed on the entire track
Securing excellent safety
Simple and convenient operation
Considering convenience of an operator / With adoption of an easy-operable
joystick, minimizing confusion upon working
Major Specification
ItemDescription
Name of MachineAerial Lift Truck
TypeSB-7500
Dimension(Length X Width X Height)2,870 × 1,460 × 1,980
Upon extension of the extended table (mm)3,005
Max. ascending height (mm)2,690
The height up to the working table upon max. descending (mm)860
A horizontal angle of the left, right and the front (˚)10 / 10 / 10
ItemDescription
Weight of Vehicle (kg)1,502
Max. Load (kg)250
Running MethodInfinite Track Type (driven by a motor)
A driving motor type48V, 1.6KW
An illumination typeA lever type (a joystick)
Running Speed (km/h)2.4
Type of Hydraulic DeviceHydraulic Power Pack(The highest oil pressure15MPa)
A video of product
A plate-typed and motorized high-place work vehicle
SB-7500S
A motorized table-type with the divided 4 sections of the extended working table
Certified as a new technology by Ministry of Agriculture, Food and Rural Affairs
Possessing many patents regarding agricultural vehicles for high-place works
MORE
Features and Performance
A motorized table-type with the divided 4 sections
of the extended working table
It is possible to extend the working table so that a work can be done up to 4m of the span length.
With the divided 4 sections, it is possible to extend them respectively according to worker’s convenience.
The length of the extended working table 2,440mm
The height of a basic working table 865mm The length of a basic working table 1,430mm
The height of a basic working table 2,110mm
The maximum height available for works 3.9m
865mm The height of a basic working table
The maximum height available for works 3,910mm
A function of adjusting the level for the front, left and right on the sloped topography
Major functions of product
A smart control system
a touch screen, an emergency mode operation, voice-enabled
Easily operable even by women and the aged
A double-cylinder type
Preventing the working table from shaking by a double-cylinder support
Safe without deformation of a frame
An audio system
A radio and a cigar jack
With a multipurpose compartment, it is convenient upon working.
Amenities
A non-slip pad and a cushion withstanding the equipment
An EVA cap to prevent rust and foreign materials and a platform brush
A safety device for emergency stop
It guarantees the safety of a worker
since it stops operation upon emergency by the emergency stop button.
A communication system
It is easy to provide a quick customer service
by an alarm and a signal check through communication between controllers.
A low-centered design
With a low-centered design method,
excellent safety upon a function of the left and right level.
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
minimizing vibration
An automatic extension of working table
Upon sliding, it is easy for a worker to use
since the subsidiary extended working table is automatically opened.
A remote control system
It is possible for simple and convenient operation
by a separate remote controller.
Optimal safety
Loads distributed on the entire track
Securing excellent safety
Simple and convenient operation
Considering convenience of an operator / With adoption of an easy-operable
joystick, minimizing confusion upon working
Major Specification
ItemDescription
Name of MachineAerial Lift Truck
TypeSB-7500S
Dimension(Length X Width X Height)2,265 × 1,370 × 1,915
Upon extension of the extended table (mm)2,440
Max. ascending height (mm)2,110
The height up to the working table upon max. descending (mm)865
A horizontal angle of the left, right and the front (˚)8 / 8 / 8
ItemDescription
Weight of Vehicle (kg)1,075
Max. Load (kg)200
Running MethodInfinite Track Type (driven by a motor)
A driving motor type48V, 1.6KW
An illumination typeA lever type (a joystick)
Running Speed (km/h)2.4
Type of Hydraulic DeviceHydraulic Power Pack(The highest oil pressure15MPa)
A plate-typed and motorized high-place work vehicle
SB-7600
A motorized table-type with the divided 4 sections of the extended working table
Certified as a new technology by Ministry of Agriculture, Food and Rural Affairs
Possessing many patents regarding agricultural vehicles for high-place works
MORE
Features and Performance
A motorized table-type with the divided 4 sections
of the extended working table
It is possible to extend the working table so that a work can be done up to 8m of the span length.
With the divided 4 sections, it is possible to extend them respectively according to worker’s convenience.
The length of the extended working table 5,220mm
The height of a basic working table 735mm The length of a basic working table 1,600mm
The height of a basic working table 2,300mm
The maximum height available for works 4.1m
735mm The height of a basic working table
The maximum height available for works 4,100mm
A function of adjusting the level for the left and right on the sloped topography
Major functions of product
A smart control system
a touch screen, an emergency mode operation, voice-enabled
Easily operable even by women and the aged
A double-cylinder type
Preventing the working table from shaking by a double-cylinder support
Safe without deformation of a frame
An audio system
A radio and a cigar jack
With a multipurpose compartment, it is convenient upon working.
A low-centered design
With a low-centered design method,
excellent safety upon a function of the left and right level.
Amenities
A non-slip pad and a cushion withstanding the equipment
An EVA cap to prevent rust and foreign materials and a platform brush
A safety device for emergency stop
It guarantees the safety of a worker
since it stops operation upon emergency by the emergency stop button.
A communication system
It is easy to provide a quick customer service
by an alarm and a signal check through communication between controllers.
A LED light
A self-waterproofing function
A super power-saving LED light
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
minimizing vibration
AC motor installed
A semi-permanent life, preventing it from being pushed back upon stopping a back-piece
Upon illumination, it is possible for a fine control.
An automatic extension of working table
Upon sliding, it is easy for a worker to use
since the subsidiary extended working table is automatically opened.
A remote control system
It is possible for simple and convenient operation
by a separate remote controller.
Optimal safety
Loads distributed on the entire track
Securing excellent safety
Simple and convenient operation
Considering convenience of an operator / With adoption of an easy-operable
joystick, minimizing confusion upon working
Major Specification
ItemDescription
TypeSB-7600
Dimension(Length X Width X Height)2,690 × 1,850 × 1,575
Upon extension of the extended table (mm)5,220
Max. ascending height (mm)2,300
The height up to the working table upon max. descending (mm)735
A horizontal angle of the left, right and the front (˚)10 / 10 / 10
Rotation angle (˚)360 degree infinite rotation
ItemDescription
Weight of Vehicle (kg)1,570
Max. Load (kg)250
Running MethodInfinite Track Type (driven by a motor)
A driving motor type48V, 1.6KW
An illumination typeA lever type (a joystick)
Running Speed (km/h)2.4
Type of Hydraulic DeviceHydraulic Power Pack(The highest oil pressure15MPa)
A boom-typed motorized high-place work vehicle
SB-8000N
A two-step bending boom-typed vehicle for high-place works
Certified as a new technology by Ministry of Agriculture, Food and Rural Affairs
The best premium model for a boom type
MORE
Features and Performance
The best workability with
infinite rotation of SB8000N_360 degree
The height of a basic working table 3,660mm
The maximum height available for works 5.4m
440mm 1,700mm
The maximum height available for works 5,460mm
A horizontal access work (Width of works 3m)
A horizontal access work Minimizing damages on fruit trees Width available for works 3,000mm
A horizontal control device
Left
Right
Front
Rear
Increasing the degree of freedom of works
Reducing vibration of the boarding platform, improving work efficiency
2-step boom 1-step boom
Major functions of product
A smart control system
a touch screen, an emergency mode operation, voice-enabled
Easily operable even by women and the aged
Applying the first 2-joint in the country
Optimizing a working table and accelerating the working speed
Minimizing damages on fruit trees
An audio system
A radio and a cigar jack
With a multipurpose compartment, it is convenient upon working.
A low-centered design
With a low-centered design method,
excellent safety upon a function of the left and right level.
A safety device for emergency stop
It guarantees the safety of a worker
since it stops operation upon emergency by the emergency stop button.
A communication system
It is easy to provide a quick customer service
by an alarm and a signal check through communication between controllers.
A LED light
A self-waterproofing function
A super power-saving LED light
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
minimizing vibration
AC motor installed
A semi-permanent life, preventing it from being pushed back upon stopping a back-piece
Upon illumination, it is possible for a fine control.
Optimal safety
Loads distributed on the entire track
Securing excellent safety
Simple and convenient operation
Considering convenience of an operator / With adoption of an easy-operable
joystick, minimizing confusion upon working
Major Specification
ItemDescription
TypeSB-8000N
Dimension(Length X Width X Height)2,660 × 1,350 × 1,710
Max. ascending height (mm)3,740
The height up to the working table upon max. descending (mm)500
A horizontal angle of the left, right and the front, rear (˚)10 / 10 / 10 / 10
Rotation angle (˚)a 140-degree revolution
1-step·2-step angle (˚)1-step 70 degrees, 2-step 95 degrees
ItemDescription
Weight of Vehicle (kg)1,155
Max. Load (kg)100
Running MethodInfinite Track Type (driven by a motor)
A driving motor type48V, 1.6KW
An illumination typeA lever type (a joystick)
Running Speed (km/h)2.4
Type of Hydraulic DeviceHydraulic Power Pack(The highest oil pressure15MPa)
A video of product
A boom-typed motorized high-place work vehicle
SB-6000S
A two-step bending boom-typed vehicle for high-place works
Certified as a new technology by Ministry of Agriculture, Food and Rural Affairs
The best premium model for a boom type
MORE
Features and Performance
좌우 140도 회전
작업 가능폭 6m
The height of a basic working table 3,140mm
The maximum height available for works 5m
380mm 1,470mm
The maximum height available for works 4,940mm
A horizontal access work (Width of works 3m)
A horizontal access work Minimizing damages on fruit trees Width available for works 3,000mm
A horizontal control device
Left
Right
Increasing the degree of freedom of works
Reducing vibration of the boarding platform, improving work efficiency
2-step boom 1-step boom
Major functions of product
Applying the first 2-joint in the country
Optimizing a working table and accelerating the working speed
Minimizing damages on fruit trees
An audio system
A radio and a cigar jack
With a multipurpose compartment, it is convenient upon working.
A low-centered design
With a low-centered design method,
excellent safety upon a function of the left and right level.
A safety device for emergency stop
It guarantees the safety of a worker
since it stops operation upon emergency by the emergency stop button.
A communication system
It is easy to provide a quick customer service
by an alarm and a signal check through communication between controllers.
A LED light
A self-waterproofing function
A super power-saving LED light
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
minimizing vibration
AC motor installed
A semi-permanent life, preventing it from being pushed back upon stopping a back-piece
Upon illumination, it is possible for a fine control.
Optimal safety
Loads distributed on the entire track
Securing excellent safety
Simple and convenient operation
Considering convenience of an operator / With adoption of an easy-operable
joystick, minimizing confusion upon working
Major Specification
ItemDescription
Name of MachineAerial Lift Truck
TypeSB-6000S
Dimension(Length X Width X Height)2,840 × 1,350 × 1,470
Max. ascending height (mm)3,085
The height up to the working table upon max. descending (mm)380
A horizontal angle of the left, right (˚)10 / 10
1-step·2-step angle (˚)1-step 70 degrees, 2-step 110 degrees
ItemDescription
Weight of Vehicle (kg)947
Max. Load (kg)100
Running MethodInfinite Track Type (driven by a motor)
A driving motor type48V, 1.6KW
An illumination typeA lever type (a joystick)
Running Speed (km/h)2.4
Type of Hydraulic DeviceHydraulic Power Pack(The highest oil pressure15MPa)
A multipurpose-type motorized high-place work vehicle
SB-9000
Multipurpose functions of a forklift, a lorry and a vehicle for high-place works
Certified as a new technology by Ministry of Agriculture, Food and Rural Affairs
Possessing many patents regarding agricultural vehicles for high-place works
MORE
Features and Performance
A function of a vehicle for high-place works
Width available for works 2.22m
It is possible to extend up to 2.22m with the detachable working table.
A length when a working table is detached 1,320mm A length when a working table is attached 1,320mm
The length of the extended working table 2,220mm
The height of a basic working table 2,500mm A length of the extended working table 520mm
The maximum height available for works 4.3m
The height of a basic working table 1,830mm
Available for works with front-tilted 6 degree and back-tilted 12 degree of a forklift
Major functions of product
A detachable working table
With the detachable working table,
it is possible to extend the working table and to work at a high place.
A low-centered design
With a low-centered design method,
excellent safety upon a function of the left and right level.
A safety device for emergency stop
It guarantees the safety of a worker
since it stops operation upon emergency by the emergency stop button.
A remote control system
It is possible for simple and convenient operation
by a separate remote controller.
A communication system
It is easy to provide a quick customer service
by an alarm and a signal check through communication between controllers.
A LED light
A self-waterproofing function
A super power-saving LED light
An upgraded suspension device
Upgraded to a structure of avoiding leaving the track
minimizing vibration
AC motor installed
A semi-permanent life, preventing it from being pushed back upon stopping a back-piece
Upon illumination, it is possible for a fine control.
Optimal safety
Loads distributed on the entire track
Securing excellent safety
Simple and convenient operation
Considering convenience of an operator / With adoption of an easy-operable
joystick, minimizing confusion upon working
Major Specification
ItemDescription
Dimension(Length X Width X Height)2,590 × 1,320 × 1,830
Upon extension of the extended table (mm)2,220
Max. ascending height (mm)2,500
A horizontal angle of the front, rear (˚)6 / 12
Type of Hydraulic DeviceHydraulic Power Pack(The highest oil pressure15MPa)
ItemDescription
Weight of Vehicle (kg)1,517
Running MethodInfinite Track Type (driven by a motor)
A driving motor type48V, 1.6KW
An illumination typeA lever type (a joystick)
Running Speed (km/h)2.4
A video of product

203, Gongdan-ro, Waegwan-eup, Chilgok-gun, Gyeongsangbuk-do, Republic of KoreaTEL : +82-54-977-3838, 3831FAX : +82-54-977-3830E-mail : sungboo@isungboo.com
COPYRIGHT 2019 TexPertise. ALL RIGHTS RESERVED.
